SCALES MANUFACTURING |
| |
 |
Robustness and performance at the right price
We have been cooperating with the largest scale manufacturers for more than twenty years, providing them with the best components for their products.
We produce load cells, electronics and many accessories specially designed for the construction of industrial and commercial scales: retail scales, postal scales, counting machines, medical scales and industrial weighing platforms.
These components are approved for trade transactions (OIML, NTEP) and are available in different materials and protection levels for use in the most difficult environments.
|
|
 |
| |
 |
|
 |
|
 |
SINGLE-CELL SCALES
 Single point load cells are characterized by independent measurement from the position of the load on the platform. They are ideal for making retail scales, postal scale and medical scales.
Our wide range of load cells is sufficient to make most single-cell scales, regardless of their environment and their use.
• Capacity from 200 g to 1 500 kg
• Platform size up to 1 000x1 000mm
• Accuracy up to 6 000d according to OIML R60
• ATEX approval for use in hazardous areas
For harsh environments
The AK load cell is made of stainless steel and is IP68 welded seal, making it an ideal solution for weighing in a wet or aggressive environment.
It can be used to make scales from 6 to 300 kg with a platform size of up to 600x600 mm.
|
 |
MULTI-CELL SCALES
To make multi-load cell weighing platforms, our range of shear beam load cells offers high performance and robustness regardless of how and in what environment your scales are to be used.
Our SB30X, SK30A and SK30X load cells are specially designed for this application, and provide excellent resistance to lateral forces, low sensitivity to changes in the load application point and have an aligned output signal to facilitate corners adjustment of the scale.
These load cells can be supplied with scale stands specially designed to limit the influence of disturbing forces.
An excellent load cell
The SK30X stainless steel load cell is approved up to 6000d OIML R60, it is IP68 sealed, can be used in explosive zones, and is typical of the high quality level that we offer you. |
 |
 |
 |
 |
 |
 |
AK |
Stainless steel single point load cell |
6, 12, 30, 60, 120, 300 kg |
C3 |
 |
AR |
Aluminum single point load cell |
0.2, 0.6, 1.2 kg |
±0.02 % |
 |
AQ |
Aluminum single point load cell |
5, 10, 15, 20, 35 kg |
C3, C4 |
 |
AG |
Aluminum single point load cell |
1, 2.5, 5, 10, 15, 20, 30, 50, 75, 100 kg |
C1.5, C3, C6 |
 |
AH, AHN |
Aluminum single point load cell |
30, 50, 75, 100, 200, 250 kg |
C3, C6 |
 |
AP |
Aluminum single point load cell |
75, 100, 150, 200, 300, 500, 635, 1 500 kg |
C3 |
 |
AB |
Aluminum single point load cell |
50, 75, 100, 150, 200, 250, 300, 500 kg |
C3 |
 |
PM |
Aluminum single point load cell |
150 kg |
±0.03 % |
 |
F60X |
Stainless steel bending beam load cell |
5, 10, 20, 50, 100, 200, 300, 500 kg, 1 t, 2 t, 5 t |
C1.5, C3, C4, C6 |
 |
SB30X |
Stainless steel shear beam load cell |
500, 750 kg, 1.2 t, 2 t |
C3 |
 |
SK30X |
Stainless steel shear beam load cell |
300, 500 kg, 1 t, 2 t, 3 t, 5 t |
C3, C6 |
 |
LFA |
Stainless steel swivel foot for load cell |
up to 2 t |
For Load cells SK30A and SK30X |
 |
LFC |
Swivel foot for load cell |
up to 5 t |
For load cells F60X, SK30A, SK30X |
 |
IPC50 PLBOX |
Weighing terminal, table housing |
LCD 25 mm display, numeric keyboard |
10 000 d, OIML R76 |
 |
IPE50 Panel |
Front panel weighing indicator |
LED 18 mm display |
10 000 d, OIML R76 |
 |
IPE50 DIN |
DIN rail housing weighing indicator |
LED 9 mm display |
10 000 d, OIML R76 |
 |
ALCJB-A |
Junction box for analog load cells |
4, 6, 8 load cells, lightning protection |
- |
 |
Analog cable |
Connection cable for analog load cells |
6-wire shielded connection |
- |
 |
TP200 |
Panel printer for IPC50, IPE50 |
thermal 24/40 col. |
- |
 |
SYSTEX |
ATEX system certificate |
For ATEX measuring chain |
- |
 |
B15, B16, B19 |
ATEX Zener barriers kit |
for ATEX measuring chain |
- |
 |
Calibration kg |
Weighing calibration |
6 t in tension, 20 t in compression |
< ±0.02% |
|
|
